Robertson PSP2GPH25HOIVDW Electronic Programmed Start Ballast 120-277V

Electronic Program Start Ballast (for Preheat Start Lamps), 600mA nominal lamp current with an Arc voltage between 45V-116V, Input voltage of 100-277Vac, for 2/1 25W Lamps or for 1 37W-70W Lamp, 50-60Hz, dual entry connectors (no leads.

FEATURES:
- Power LED connectors (2.5V)
- Lamp LED connectors (2.5V)

PERFORMANCE:
- Max Current THD = <12%
- Current Crest Factor = <1.7
- Power Factor = > 0.95
- Encased & Potted
- Sound Rated A
- All-star (EOL) Protection
- Meets FCC Part 18 (Class B) for EMI and RFI Consumer Limits
- Meets CE Requirements (120-240V)
- Meets ANSI Standard C62.41 for Transient Protection
- Meets ANSI Standard C82.11 for Ballast Requirements

APPLICATION:
- Maximum Case Temperature 185F/85C
- Maximum Ambient Temperature 140F/60C
- Minimum Starting Temperature -22F/-30C
- Lamp Starts >50,000 Starts
- Remote Mounting 18 ft. Max. Lead Length, 18AWG

SAFETY/STANDARDS:
- UL/935 Listed (Class P, Type 1 Outdoor)
- cUL (CSA/C22.2 Certified)
- No PCBs, Type HL, Type CC
- Inherent Thermal Protection
- RoHS Compliant

Ballast Type	Electronic
Starting Method	Program
Unit Color	White
Input Voltage	100-277Vac 10%
Lamp Connection	Series
Input Frequency	50-60Hz

- DULUX L 55 W/865 2G11
- G25T8/OF
- GFT55DL/2G11/SE
- HNS 25W G13
- HNS 55 W G13
- HNS L 55W 2G11
- TUV 25W 1SL
- TUV PL-L 55W/4P HF
- 23401 Osram HNS L 55W 2G11
- 55197 Osram HNS 25W G13

Manual:

PSP2GPH25HOIVDW Data Sheet
